Description
Sampling Modes:
Real-time sampling mode:
Auto-simultaneous, Auto-sequential manual, Rhythm (1-5 min)
Pre-sampling mode
Triggered sampling mode
Periodic sampling mode Sampling Mode
Real-time sampling mode:
Auto-simultaneous, Auto-sequential manual,
Rhythm (1-5 min)
Pre-sampling mode
Advanced ECG Analysis
Equipped with the Glasgow Algorithm providing intelligent ECG diagnostic interpretation and automatically generating diagnostic conclusions. according to age, gender, race, medication history and etc., especially for AMI, Ventricular Fibrillation, Ventricular Tachycardia, quarterly Bradycardia, malignant arrhythmia.
Intelligent ECG Detection
Automatically detects and labels pacemaker signals while identifying electrodes with poor contact, ensuring accurate and reliable ECG recordings.
Advanced Sampling & R-R Analysis
support Real-time, Pre-sampling, Triggering sampling and Period sampling mode. And R-R Histogram and R-R chart are available.
Advanced Report Management
With report management function, it supports report preview, query, editing, printing, and transmitting.
Advanced VCG & TVCG Analysis
TVCG and VCG functions are available as optional features. The VCG provides a comprehensive representation of cardiac electrical activity and supports ECG waveform analysis, with significant diagnostic value for myocardial infarction, bundle branch block, and ventricular hypertrophy.
Alarm
Standard Accessories
- Main Unit
- Limb Electrodes-
- Adult/IEC/4 per Set
- Chest electrodes-Adult/IEC/6 per Set
- ECG Cable-ECG Cable\12-lead/banana plug
- Power cord
- Thermal paper-210mm×140mm/20m
- Ground wire-Clip type
Optional
Patient Cable
- Banana type ECG cable
- Snap type ECG cable
- Clip type ECG cable
Electrodes:
- Chest electrodes-Adult/pediatric
- Limb electrodes-Adult/pediatric
- Disposable electrodesSnap Type Adult/Pediatric
- Electrodes adapter
Optional high-quality trolley
Easy to use in various scenes of the hospital.
| Category | Details | |
|---|---|---|
| Technical Specifications | Screen Size | 10.4" touch LCD |
| ECG Lead wire (leads) | 12-lead synchronous acquisition and display | |
| Screen Resolution | 1024 x 768 pixels | |
| Sampling rate (Hz) | 32000 samples per second (or Hz/channel) | |
| HR Measuring range | 30bpm~350bpm | |
| (CMRR) | ≥115dB | |
| Frequency response | 0.01~350Hz | |
| Input impedance | ≥ 60 MΩ (10 Hz) | |
| A/D conversion | 24 bits | |
| Time constant | ≥3.2S | |
| Sensitivity | 40, 20, 10, 5, 2.5, Auto mm/mV | |
| Polarization voltage | ±950mV±3% | |
| External interface | 2 USB ports, LAN connectors, SD card slot; Support to connect to keyboard, mouse, card reader, printer and etc. | |
| Network | Wi-Fi and cable networking | |
| Data format | ZQECG, JPG, PDF, PNG, XML, HL7, DICOM-JPG, DICOM-PDF, DICOM-WAVEFORM | |
| System Noise | RTI, peak-to-valley value: ≤15m | |
| Analysis algorithm | Glasgow | |
| Storage | Local ≥20,000 reports USB (SD card) Reports can be saved directly in USB (SD card) only when it is inserted. Reports are stored in ZQECG format and can be viewed on our ECG Machine or ECG workstation. | |
| Filter Setting | AC: off/50/60Hz Baseline Drift: off/0.01/0.05/0.3/0.6Hz EMG: off/25/35/45/75/100/150/250/350Hz | |
| Freeze | Max 60 s waveform freezing and review function | |
| Power Specifications | AC Power | 100V-240V, 50Hz/60Hz, 120proVA |
| Battery | Working time ≥10.5 hours Rechargeable li-ion battery (14.52V/5200mAh) | |
| Dimensions and weight | Tablet Weight | 1.2 kg |
| Â | Tablet Size (H x W x D) | 285 mm x 360 mm x 94 mm |
| Printing Specifications | Paper Specifications | Z-fold Paper; 210mm/216mm* 140mm-20m |
| Paper Speed | 5, 6.25, 10,12.5, 25, 50 mm/s | |
| Recording Mode | Thermal array printer; 8 dot/mm (vertical) 40 dot/mm (horizontal, 25mm/s) | |
| Printing Duration | 2.5 sec, 5 sec, 7 sec, 10 sec, Two pages, Three pages, Four pages |
