Description
Desferal Pump
DP-1
Bright OLED Screen
Bright & Energy saving OLED screen displays both infusion rate and alarm message.
Alarm Indicators
An immediate identi caion of pump's alarm and alert messages.
Features
Multiple Alarm Signal
Audible, visual and vibration alerts.
Parameter Memory
Automatically retains configured parameters
Injection mode
Rate Control Mode
Compatible with all brands
1ml-20ml syringes.
Replacement Batteries
Compact power format using three AA batteries
Flow Rate by Syringe Size
| Syringes Size | Flow Rate Range |
|---|---|
| 20 ml | 0.1 up to 99.9 ml/hr |
| 10 ml | 0.1 up to 99.9 ml/hr |
| 5 ml | 0.1 up to 75.5 ml/hr |
| 2.5 ml | 0.1 up to 39.6 ml/hr |
| 1 ml s | 0.1 up to 10.9 ml/hr |
PORTABLE BY DESIGN
Light weight
Replacement Batteries
Compact
Carying Bag
| Main Technical Parameters | |
|---|---|
| Power supply | DC3.0V～5.0V(3×AA batteries or 3*Ni-MH Battery) |
| Linear Flow Rate | 1 mm/hr～99 mm/hr (equals to 0.2 cc/h～20 cc/h) |
| Applicable Syringe | 1ml～50ml* disposable syringes |
| Syringe Accuracy | Continuous injection less than ± 2 % |
| Battery life | 300 days or minimum continuation injection 72h syringes |
| Alarms | Alarms Battery Depleted, Mechanical Error, Occlusion, Syringe Disengaged, Completion |
| Alerts | Battery Low, User Prompt, Syringe Not Installed. Near End |
| Injector | 5 defined injectors+5 User-defined injector |
| P.C.A. Function | Can preset value |
| Occlusion Pressure | Less than 0.16Mpa |
| Working time | Up to 72 hours continuous injection after full charged |
| Battery | Rechargeable lithium-ion battery 3.7V 4000mAh |
| (BOLUS) | Easily adjust the bolus rate with need User-defined Bolus time and volume Bolus choose from start or during infusion |
| Security | Key lock |
| Weight | 180 g / 0.55 lb (240 g with 3 AA batteries) |
| Dimensions | W 165 × H 60 × D 30 mm (6.5"W × 2.4"H × 1.2"D) |
Applications
Thalassemia
Parkinson
Neonatal Care
