Description
Infusion Pump
IP-1
| Parameter | Specification Value |
|---|---|
| Patient Demographic | Premature neonates, newborns, and pediatric infants up to 14 years of age. |
| Oxygen Concentration (iOâ‚‚) | 21% to 100% continuous mechanical adjustment. |
| Flow Rate Control | Adjustable from 2 to 18 Liters Per Minute (LPM). |
| CPAP Pressure Range | 3 to 10 cmHâ‚‚O managed via physical water-column oscillation. |
| Acoustic Noise Level | ≤ 55 dB(A) to sustain low-noise developmental protocols in critical care zones. |
| Power Input Requirements | AC 220V, 50-60Hz (Optional localized variant: AC 110V, 50-60Hz). |
| Input Gas Source Pressure | Air and Oxygen lines balanced at 0.3 MPa to 0.4 MPa. |
| Safety Monitoring Alarm | Automated pneumatic alert triggers if gas supply pressure differential exceeds >0.1 MPa. |
Features
All-in-One Neonatal Support
Integrates blender, humidifier, and bubble generator into a complete system.
Visual Clinical Operation
Fast, easy visual monitoring and adjustment of flow, FiO2, humidity, and pressure.
Modular Column Design
Vertical pole layout saves space, ensures clean separation, and allows quick servicing.
Active Airway Protection
Compatible with servo-controlled humidifiers to deliver safely heated, moisture-saturated gas.
Adaptive Patient Fit
Supports reusable or disposable circuits with sizes of anatomical nasal prongs.
Pipeline Package
Core system with trolley stand –(requires centralized hospital air supply).
System Components And Heated Wire Option
Standard Components
Humidification chamber
Humidifier
Medical air compressor
Air oxygen blender
Horizontal nasal prong set
Bubble generator
Interface nasal prong set
Reusable silicone tube set
Bubble CPAP with Heated Wire (Optional)
Disposable circuit with heated wire
IV pole
Servo-control humidifier
